Diffusion Media CC-600 G

Fine air filtration media specifically designed to be used in down-draft paint spray booths as the final filtration barrier to all paint damaging particles from the intake air stream. This Ceiling Filter or Diffusion media ensures a uniform air distribution and a laminar flow throughout the spray booth, when applied in auto assembly plants and auto refinishing facilities. Synthetic fiber-based filter media developed and manufactured at high-tech media plant based in The Europe. The filter media is constructed from selected high performance, non-breakable fibers in a progressive density multi-layering technique allowing high depth loading to ensure high dust holding capacity with optimal lowest pressure drop performance. This media is thermally bonded and impregnated in full depth with a special tackifier coating to prevent any release of fibers and migration of paint damaging particles larger than 5 microns due to vibration in the system, even under varying temperature conditions. CC-600 G is classified as R0 in accordance with the migration test. This results in high fractional efficiency combined with a high dust loading capacity, a long filter life as well as low energy and maintenance costs.

This high-quality Ceiling or Diffusion media is specially designed to be used in the ceiling of paint spray facilities in auto assembly plants and down draft spray cabins of auto refinishing facilities as well as in paint spray booths of the repair after markets. This media enhances a very uniform air distribution and a laminar air flow. Further, it acts as the final filtration barrier to paint damaging particles from the air stream which is an absolute requirement for high gloss and high-tech performance finishes.
